Roll-up Garage Door
High Speed Roll-up Door,with a speed of more than 0.6 meters per second, is a fast lift barrier-free isolation type. The main function is to ensure workshops dust-free. It is thermal insulated, insect-proof, wind-proof, dustproof, soundproofing, fire-retardant and odor-proof.
- Product details
Product parameters
1. Control box:
composed of Hailip frequency converter, computer programming PLC and various commonly used protection devices, built-in vector control mode, high control accuracy; high torque inverter (150% 1HZ), PLC combined into one, with High performance, high reliability, high stability, high precision positioning and other characteristics. At the same time, the use of frequency conversion control technology has soft start and slow stop functions to ensure the smooth operation of the door body and increase the service life.
2. Power system: Sino-Italian joint venture SEJ special motor for fast rolling door.
1. Power: 1.5KW Select the required model according to the size of the door.
2. Voltage: 220V stable performance.
3. Rotation speed: 1500 rpm, F: IP55, can meet the requirements of high-frequency opening.
4. Advantages: S4 type with large load, the latest generation of reduction gears, high efficiency, energy saving and low noise.
3. Door structure:
1. Door box, door legs, hood: high-quality carbon steel, thickness 2.0MM thick, the surface is treated by high-temperature powder electrostatic spraying process (color is optional), the door head is made of cold rolled steel plate structure, After repeated anti-rust treatment, the surface is treated with high-temperature powder coating; smooth; bright, the color is the same as the door frame.
2. Curtain: The material of the curtain is high-density industrial coated base fabric, which is produced in France (thickness 0.8mm), and the color is blue, yellow, white, etc. The technical parameters are: tensile strength: (warp / weft) 4000 / 3500N tear strength: (warp / weft) 600 / 600N, the use temperature is between -30 ℃ and + 70 ℃. Fire rating: German standard DIN75200. Fire-retardant, flame-retardant and self-sustaining. The curtain divider processing can be replaced by itself.
3. Perspective window: Low temperature resistant and anti-aging PVC perspective window, the use temperature is -40 ℃ to + 70 ℃, and the position is above 1.2-1.5m, which increases the safety performance, management performance and lighting rate.
Fourth, the control and use:
1, the use of two-sided manual buttons: up, down, emergency stop, switch, easy to use.
2. Photoelectricity (Jetek): The photoelectric protection switch is installed at the bottom of the door body, and any objects within the photoelectric range will not be closed if the door is quickly rolled, which better protects the safety of people and objects.
3. Emergency configuration for power failure: The strap-type stacking door is equipped with a manual rocker device. In case of power failure or failure, the manual rocker can be used to control the strap-type stacking door to open or close.
4. Switching: The strap-type stacking door is in the standby state, and can be manually switched and automatically switched. It is suitable for two use environments and extends the service life of the stacking door.
Fifth, the speed of the strap-type stacking door:
1. The strap-type stacking door has an opening speed of 0.7-1.7m / sec (adjustable) to ensure fast, efficient and energy-saving, and the high-speed opening also makes the strap-type stacking door subject to collision The danger is reduced to a minimum, even if the strap-type stacking door is hit, it does not require any special tools or skills to restore the strap-type stacking door in a short time.
2. Opening and closing times: the opening and closing times can reach 1000-1500 times / day.
6. The
rails on both sides of the sealed door frame are equipped with sealing brushes, which are insect-proof and dust-proof. They can also prevent wind and reduce noise, block fine dust particles floating in the air, and are suitable for 10,000-300,000-level purification workshops. Strong performance, no dust accumulation, high efficiency, stability, waterproof and easy to clean. The bottom end is equipped with a heavy air barrier cloth (PVC base cloth), which can be closely combined with various uneven floors to achieve a better sealing effect.
Seven, wind resistance effect
strap-type stacking door is equipped with high strength anti-oxidation aluminum alloy reinforcement, wind resistance capacity: 20m / s. Aluminum windproof reinforced ribs and structured fabric door curtains not only increase the aesthetics and firmness, but also have a good sealing effect when the stacking roller doors are stacked under harsh environmental conditions.
8. Quality assurance: The strap-type stacking door is guaranteed for one year free from the date of installation and acceptance by the buyer (except for natural disasters and human factors).
composed of Hailip frequency converter, computer programming PLC and various commonly used protection devices, built-in vector control mode, high control accuracy; high torque inverter (150% 1HZ), PLC combined into one, with High performance, high reliability, high stability, high precision positioning and other characteristics. At the same time, the use of frequency conversion control technology has soft start and slow stop functions to ensure the smooth operation of the door body and increase the service life.
2. Power system: Sino-Italian joint venture SEJ special motor for fast rolling door.
1. Power: 1.5KW Select the required model according to the size of the door.
2. Voltage: 220V stable performance.
3. Rotation speed: 1500 rpm, F: IP55, can meet the requirements of high-frequency opening.
4. Advantages: S4 type with large load, the latest generation of reduction gears, high efficiency, energy saving and low noise.
3. Door structure:
1. Door box, door legs, hood: high-quality carbon steel, thickness 2.0MM thick, the surface is treated by high-temperature powder electrostatic spraying process (color is optional), the door head is made of cold rolled steel plate structure, After repeated anti-rust treatment, the surface is treated with high-temperature powder coating; smooth; bright, the color is the same as the door frame.
2. Curtain: The material of the curtain is high-density industrial coated base fabric, which is produced in France (thickness 0.8mm), and the color is blue, yellow, white, etc. The technical parameters are: tensile strength: (warp / weft) 4000 / 3500N tear strength: (warp / weft) 600 / 600N, the use temperature is between -30 ℃ and + 70 ℃. Fire rating: German standard DIN75200. Fire-retardant, flame-retardant and self-sustaining. The curtain divider processing can be replaced by itself.
3. Perspective window: Low temperature resistant and anti-aging PVC perspective window, the use temperature is -40 ℃ to + 70 ℃, and the position is above 1.2-1.5m, which increases the safety performance, management performance and lighting rate.
Fourth, the control and use:
1, the use of two-sided manual buttons: up, down, emergency stop, switch, easy to use.
2. Photoelectricity (Jetek): The photoelectric protection switch is installed at the bottom of the door body, and any objects within the photoelectric range will not be closed if the door is quickly rolled, which better protects the safety of people and objects.
3. Emergency configuration for power failure: The strap-type stacking door is equipped with a manual rocker device. In case of power failure or failure, the manual rocker can be used to control the strap-type stacking door to open or close.
4. Switching: The strap-type stacking door is in the standby state, and can be manually switched and automatically switched. It is suitable for two use environments and extends the service life of the stacking door.
Fifth, the speed of the strap-type stacking door:
1. The strap-type stacking door has an opening speed of 0.7-1.7m / sec (adjustable) to ensure fast, efficient and energy-saving, and the high-speed opening also makes the strap-type stacking door subject to collision The danger is reduced to a minimum, even if the strap-type stacking door is hit, it does not require any special tools or skills to restore the strap-type stacking door in a short time.
2. Opening and closing times: the opening and closing times can reach 1000-1500 times / day.
6. The
rails on both sides of the sealed door frame are equipped with sealing brushes, which are insect-proof and dust-proof. They can also prevent wind and reduce noise, block fine dust particles floating in the air, and are suitable for 10,000-300,000-level purification workshops. Strong performance, no dust accumulation, high efficiency, stability, waterproof and easy to clean. The bottom end is equipped with a heavy air barrier cloth (PVC base cloth), which can be closely combined with various uneven floors to achieve a better sealing effect.
Seven, wind resistance effect
strap-type stacking door is equipped with high strength anti-oxidation aluminum alloy reinforcement, wind resistance capacity: 20m / s. Aluminum windproof reinforced ribs and structured fabric door curtains not only increase the aesthetics and firmness, but also have a good sealing effect when the stacking roller doors are stacked under harsh environmental conditions.
8. Quality assurance: The strap-type stacking door is guaranteed for one year free from the date of installation and acceptance by the buyer (except for natural disasters and human factors).
